Process Design Kit
At AMF, our Photonic Design Kits (PDKs) are a cornerstone of our technological leadership. With SiPhab, our industry-leading PDK brand, we are proud to offer one of the most comprehensive and advanced Silicon Photonics PDKs globally. Trusted by designers and engineers worldwide, our PDKs are built for performance, versatility, and ease of use.
Our PDKs cover a wide range of applications—from mainstream to high-performance systems—ensuring that you have the right tools, models, and design aids to accelerate your project development. With access to industry-leading components and an extensive library of photonic devices, AMF’s PDKs are the ultimate resource for high-quality, next-gen designs.
Why Choose AMF’s PDKs?
AMF’s PDKs are not just tools—they are trusted solutions designed to power innovation and enable success. Here’s why AMF’s PDKs stand out in the world of Silicon Photonics:
- Comprehensive Device Library: With over 110 device IPs, AMF’s SiPhab PDK covers a wide range of active and passive photonic components, enabling the development of diverse and advanced photonic systems.
- Unmatched Compatibility: Fully supported by all major EDA vendors, including Luceda, Cadence, Synopsys, K-Layout, GDSFactory, and others, our PDKs seamlessly integrate into your existing workflows.
- Continuous Innovation: Our PDKs undergo regular updates driven by customer feedback and industry needs, ensuring you’re always working with the latest devices and the best performance.
Our PDK Offerings
AMF’s PDKs are structured to simplify the design process, enabling engineers to work more efficiently and effectively. To make it easier for designers to find the right tools for their specific needs, our PDKs are organized by wavelength and application type. Let’s take a look at the key devices in each PDK.
SiPhab 5.0 for GP (O-Band)
| 56GBaud Modulator | Si 1×2 MMI |
| 28Gbaud Photodetector | Si 2×2 MMI |
| Power Monitor Photodetector | Si Edge Coupler |
| 120Gbaud Photodetector | Si Grating Coupler |
| SiN 1X2 MMI | Si Polarization Beam Rotator Combiner |
| SiN 2×2 MMI | Si Polarization Beam Rotator Splitter |
| SiN to Si Spot Size Convertor | Si Polarization Beam Splitter |
| Si & SiN Crossing | Si Thermal Optical PhaseShifter |
| SiN Thermal Optical Phase Shifter | Si Variable Optical Attenuator |
SiPhab 5.0 for GP (C-Band)
| Si Edge Coupler | SiN Crossing |
| Si Grating Coupler | Si Thermal Optical PhaseShifter |
| Si 1X2 MMI | SiN Thermal Optical Phase Shifter |
| SIN 1X2 MMI | SiN to Si Spot Size Convertor |
| Si 2X2 MMI | 56GBaud Modulator |
| SiN 2X2 MMI | 110Gbaud Photodetector |
| Si Polarization Beam Rotator Combiner | 28GBaud Photodetector |
| Si Polarization Beam Rotator Splitter | 80Gbaud Photodetector |
| Si Polarization Beam Splitter | Power Monitor Photodetector |
| Si Crossing | Si Variable Optical Attenuator |
SiPhab 5.0 for HP (O-Band)
| Si Grating Coupler | 56 Gbaud Photodetector |
| Si 1X2, 2X2 MMI | 120 Gbaud Photodetector |
| Si Crossing | Power Monitor Photodetector |
| Si Thermal Optical Phase Shifter | SiN to Si Spot Size Convertor |
| 100 Gbaud Differential Modulator | SiN Edge Coupler |
SiPhab 5.0 for HP (C-Band)
| 100 GBaud Differential Modulator | Si 1X2, 2X2 MMI |
| 110 Gbaud Photodetector | Si Crossing |
| 200 SPP MOD I/O | Si Grating Coupler |
| 56 Gbaud SPP Modulator | Si Polarization Beam Rotator Combiner |
| 80 Gbaud Photodetector | Si Polarization Beam Rotator Splitter |
| SiN Edge Coupler | Si Polarization Beam Splitter |
| SiN to Si Spot Size Convertor | Si Thermal Optical PhaseShifter |
| Power Monitor Photodetector | Si Variable Optical Attenuator |
Our PDKs Guarantee Performance
When you choose AMF’s PDKs, you’re choosing reliability, rigorously tested performance, and proven success in your designs. Each of our components undergoes extensive testing to ensure it meets the highest standards. With continuous improvements based on real-world feedback, our PDKs deliver consistent performance gains that allow you to push the boundaries of Silicon Photonics.
Seamless Integration and Support
AMF’s PDKs are designed for seamless integration into your existing workflows. Supported by all the leading EDA tools, you can easily incorporate our PDKs into your design process without disruption. Whether you’re using Cadence, Synopsys, GDSFactory, Luceda, or K-Layout (and more !) our PDKs will fit effortlessly into your toolchain.
Additionally, AMF provides extensive technical support and resources to help you get the most out of our PDKs, ensuring a smooth and efficient design experience.
Continuous PDK Updates
Innovation never stops at AMF. Our frequent PDK updates ensure that you are always working with the latest devices and features. These updates are based on customer feedback, industry trends, and emerging technologies, meaning you get access to the best possible photonic solutions as soon as they are available.
- New Device Additions: Regularly adding new devices and components based on market demand.
- Enhanced Performance: Ongoing performance improvements to keep up with the evolving needs of high-speed and high-performance applications.
- Customer-Centric Updates: Our PDKs are constantly refined with input from the Silicon Photonics community to ensure you stay ahead of the curve.
Explore Our PDKs Today
Need help choosing the right PDK or have specific questions about compatibility? Our team is here to help. Reach out today and see how AMF’s SiPhab PDKs can help streamline your design process.
